XWW-200N Computer Control Tensile & Compress Universal Material
Testing Machine
Description:
Computer controlled Electronic Universal Testing Machine is
advanced testing machine model which adopt the computer close loop
control and graphic display technology. The control software is
base on the Mircrosoft Windows and has the both Chinese and English
languages version. Computer controls the whole testing process; the
software can get the test value by all kinds of sensor and using
the software analyzing module, user can get all kinds of mechanics
parameter such as tensile strength, elastic modulus and elongation
ration automatically. And all test data and result can be saved to
computer, also the system allow user to print the test report with
curve and parameter.
The XWW series testing machine is widely used in the field of
rubber, plastic, PVC pipe, board, metal wire, cable, waterproof
materials and film industry. By using different kinds of
accessories, it can do the test of tensile, compression, bending,
shear, peeling, tearing and all other kinds of testing. This is a
common testing equipment for all kinds of lab and quality control
department to determine the material quality and mechanics
analyzing.
Main technical parameter of Computer Controlled Electronic
Universal Testing Machine:
| Model | XWW-200N |
| Type | Door model |
| Max. Load | 200N |
| Unit Switchover | Tone,Kg,g,Kn,Lb; mm,cm,inch |
| Accuracy Grade | 0.5% |
| Force-measuring Range | 0.4%~100%FS |
| Force-measuring Accuracy | ≤0.5% |
| Deformation-measuring Range | 2%~100%FS |
| Deformation-measuring Accuracy | 1% |
| Crossbeam Displacement Resolution | 0.001mm |
| Crossbeam Speed Range | 0.01~500mm/min |
| Displacement Speed Accuracy | ≤ 0.5% |
| Test Width | 330mm (or according to order) |
| Tensile Space | 600mm |
| Compression Space | 900mm (or according to order) |
| Clamps | Wedge Grip,Compressing Attachment,Bend accessorises |
| PC System | Equiped with brand computer |
| Flat-specimen thickness | 0~7mm |
| Power Supply | AC220V |
| Standards | ISO 7500-1 ISO 572 ISO 5893 ASTMD638695790 |
| Size of the host | 660*420*1300mm |
| Weight | 110KG |
Introduction of the UTM software:
Universal Testing Machine Software (more than the following)
- This software is of powerful function, including programs of
tensile, compressing, bending, sheering, peeling tests on metallic,
non-metallic, and other various materials.
- Based on Windows, simple operation and easy to learn.
- Languages switch between Simplified Chinese, traditional Chinese
and English.
- Ten user accounts and passwords can be created.
- It has the protection function of overloading: overloading value
can be set by user.
- The units of force or displacement can be switched easily. The
changes in stress and strain are displayed real time.
- Curves, like Load-displacement, load-time, displacement-time,
stress-strain, load-tensile length, etc. can be switched between
each other at any time.
- Force value dual-correction system: auto set and zero, auto
identification and import of correction data.
- It is suitable for many testing standards, such as ISO, JIS, ASTM,
DIN, GB etc.
- Compare among the test curves in the same group though piling them
up.
Auto zero set. Max force, upper-yield strength, lower-yield
strength, anti-tensile intensity anti-compression strength,
elasticity modulus, percentage of elongation, etc. are calculated
automatically.
System configuration
1 Machine main unit
1 1 AC servo motor, driver 1 set
1.2 Speed reduce system 1set
1. 3 Load cell 200N1pc
1. 4 Precision precision ball screw 2sets
1. 5 Control board 1set
2 Servo control system 1set
3 Gear system 1set
4 PC 1set
5 Inkjet color printer 1set
7 Tensile test accessories 1set
8 Software installation CD 1set
9 Technical documents 1set
including : Instruction Manual
Manual of the Software
Certificate
10 Tool kit 1 set
